30HP Inverter Air-Cooled Scroll Chiller Inverter Chiller VFD Chiller Water Chiller Energy-saving Chiller Air Cooled Chiller Process Chiller

Brand Name : Bosikar

Model Number : BSKV-40AF

Certification : CE

Place of Origin : China

MOQ : 1

Price : USD

Payment Terms : T/T,L/C

Supply Ability : 300pcs/month

Delivery Time : 25 days

Packaging Details : Woodern box

Chiller Type : Air-Cooled Inverter Chiller

Cooling Capacity : 23 – 84 kW

Compressor Type : Inverter Compressor Variable Speed Compressor(VFD)

Refrigerant : R410a, R407c, R134a

Evaporator : Shell and tube

Condenser : Copper tubes with hydrophilic aluminum fins

Contact Now

30HP Inverter Air-Cooled Scroll Chiller

High Efficiency · Stable Cooling · Intelligent Control


Key Features & Benefits


1. Inverter Technology for Superior Energy Efficiency
  • High-efficiency inverter scroll compressor
  • Variable speed operation based on actual cooling demand
  • Eliminates frequent start-stop cycles
  • Energy savings of 20%–40% compared to fixed-speed chillers
  • Excellent efficiency at partial load conditions


2. Air-Cooled Design for Easy Installation
  • Integrated pump and water tank (optional)
  • No cooling tower or condenser water system required
  • Independent of water quality and water supply
  • Compact structure with small footprint
  • Ideal for locations with limited space or water resources


3. Stable Temperature Control for Continuous Operation
  • Precise water temperature control with accuracy up to ±0.1°C
  • Designed for 24/7 continuous industrial operation
  • Stable cooling output for temperature-sensitive processes


4. Industrial-Grade Construction for Long Service Life
  • High-efficiency finned air-cooled condenser
  • Optimized airflow design for improved heat dissipation
  • Key electrical components from internationally recognized brands
  • Reliable performance under high ambient temperature and heavy load conditions


5. Intelligent Control System
  • PLC-based controller with user-friendly interface
  • Real-time monitoring of operating status and parameters
  • Multiple safety protections and fault diagnostics
  • Optional communication interfaces for remote monitoring


30HP Inverter Air-Cooled Scroll Chiller Inverter Chiller VFD Chiller Water Chiller Energy-saving Chiller Air Cooled Chiller Process Chiller 30HP Inverter Air-Cooled Scroll Chiller Inverter Chiller VFD Chiller Water Chiller Energy-saving Chiller Air Cooled Chiller Process Chiller


Air-Cooled Chiller Specifications

Item

Specification

Model

BSKV-30AD

Chiller Type

Air-Cooled Inverter Chiller

Control Type

Variable Speed (Inverter / VFD)

Nominal Cooling Capacity

23 – 84 kW

Power Input

11 – 28 kW

Refrigerant

R410A

Compressor Type

Hermetic Scroll Compressor (Inverter Driven)

Evaporator

Shell and Tube Type

Condenser

Air-Cooled Finned Coil

Power Supply

380V / 50Hz (Customizable)

Chilled Water Temperature Range

5°C – 30°C

Dimensions (L × W × H)

1900 × 990 × 2050 mm

Net Weight

1250 kg


Test Conditions:
Chilled water inlet / outlet temperature: 17°C / 12°C
Ambient air temperature: 35°C

Specifications may vary depending on ambient temperature, process conditions, and customized requirements.


Installation & Maintenance Advantages
  • Outdoor or rooftop installation supported
  • Modular layout for easier servicing
  • Balanced compressor operation extends service life
  • Lower maintenance cost compared to large screw chillers

Customization & Service Support
  • Non-standard customization available
    (voltage, temperature range, special working conditions)
  • Professional selection guidance and system design support
  • Full performance testing before delivery
  • Reliable after-sales service and technical support

Typical Applications
  • Plastic injection molding and extrusion
  • Laser cutting, welding, and CNC machining
  • Mold cooling systems
  • Chemical processing and reactor cooling
  • Food and beverage processing
  • Pharmaceutical and laboratory equipment cooling
